Water Tank Truck: Your Fun and Functional Friend!
Hey there, get ready to dive into the exciting world of water tank trucks!
These awesome machines, also known as sprinklers, water tankers, sprayers, or street washers, are like the superheroes of our streets. They play a big role in keeping our roads clean, our plants happy and hydrated, our buildings looking fresh, and even help put out fires when needed.
Each water tank truck is equipped with a special fire interface, turning it into a temporary emergency fire sprinkler. Like a powerful beast, the vehicle's engine powers a gearbox. A power take-off (PTO) on the gearbox drives the sprinkler pump, which is like the heart of the operation. This pump generates the main force to propel the liquid from the tank through the pipe network.
The truck can self-prime up to a height of 7 meters. Its sprinkler width reaches up to 20 meters, and it can spray as far as 28 meters. You can adjust the spray into a columnar shape for long-distance reach or a mist shape for shorter, gentle coverage. The design typically features front spraying and rear sprinkling functions. The front is equipped with a duck-shaped nozzle or a round-headed flushing nozzle, while the rear has a cylindrical sprinkler nozzle or shower a nozzle. A working platform at the rear is fitted with a high-pressure water cannon. Additionally, the rear can optionally be equipped with 8 nozzles.
The pipeline system comprises pipes, four-position three-way ball valves, straight-through ball valves, filters, and water outlets. These water outlets include front flushing, rear sprinkling, and side spraying functions. It also features high-position side sprinklers and a rear working platform with a greening sprinkler cannon.
The cab of a water tank truck comes in two main types: pointed cab (long-head cab) and flat cab (short-head cab). Primarily used for street washing, dust removal, and cooling, the truck allows you to adjust the sprinkler nozzle's thread to change the spraying direction and angle. The cannon can be utilized for urban and rural landscaping as well as emergency firefighting. Meanwhile, the shower head is designed to irrigate the dust collected by the sprinkler in the middle of the road, helping to cleanse the air.
So, next time you see a water tank truck, remember it's not just a vehicle—it's a fun and functional friend making our world a cleaner and better place!
| Overview |
| Driving type | 6*4 LHD Driving form |
| Horsepower | 336HP |
| Transmission Type | Manual |
| Fuel Type | Diesel |
| Gross Vehicle Weight(kg) | 25000kg |
| Brand Name | SINOTRUK -HOWO |
| Truck type | ZZ1257N4641W |
| Condition | New |
| Emission Standard | EURO 2 |
| Horse Power | 336HP |
| Engine Capacity | 247 |
| Water tank capacity | 20m³ |
| Place of Origin | Shandong,China(Mainland) |
| vehicle size | 10350mmx2496mmx3050mm |
| Driving type | Left hand driving |
| 1,Basic Vehicle Information |
| Color | White, green, orange, red, color can be selected |
| Approaching angle/Departure angle(°) | 19/23 |
| Wheel base (mm) | 3425+1350 |
| Axle number | 3 |
| Drive shaft | Second and third axes |
| Gross Vehicle Weight(kg) | 25000 |
| 2,Engine |
| Engine type | WD615.95 |
| Horse Power | 336HP |
| Vehicle torque(N-m) | 1350N.m |
| Maximum Torque and Speed | 1100-1600rpm |
| Rated speed | 2200rpm |
| Engine type | Inline six-cylinder, water-cooled, four-stroke, supercharged intercooler, high pressure common rail, SCR |
| Emission Standard | EURO 2 |
| Engine power(kw) | 247kw |
| Engine weight(kg) | 850kg |
| Number of engine cylinders | 4 |
| 3,Transmission |
| Transmission | HW19710 |
| 4,Vehicle chassis |
| Allowable Load of Front Bridge(kg) | 9000 |
| Allowable Load of Rear Bridge(kg) | 16000 |
| Fuel tanker capacity(L) | 300 |
| ABS | Optional |
| Tyre type | 12.00R20 |
| Tyre number | 10+1,Plus a spare tire |
| Types of lifting transportation | Hydraulic front support |
| Front axle type | HF9 |
| Rear axle type | HC16 |
| Rear axle ratio | 5.7 |
| Cab Passenger Number | 3 |
| Cab type | HW76 |
| Air conditioning | YES |
| Frame type | 8+8/300 |
| ABS | NO |
| 5,Water tank parameters |
| Water tank capacity | 20m³ |
| Tank thickness | 5mm |
| Tanker dimension | 7650mmx2326mmx1450mm |
